Description
The past several decades in networking have been defined by static, closed networking solutions designed for the client-server era. The Aruba 8320 JL579A Switch Series, a campus core and aggregation switch, is a game-changing solution that offers an innovative approach to dealing with the demands of the mobile, cloud and IoT era. The Aruba 8320 is based on ArubaOS-CX, a modern software system that automates and simplifies critical and complex network tasks, delivers enhanced fault tolerance and facilitates zero-service disruption during planned or unplanned control-plane events. The key innovations in ArubaOS-CX are its micro-services style modular architecture, REST APIs, Python scripting capabilities and the Aruba Network Analytics Engine. The Aruba 8320 Switch Series provides line rate 10GbE and 40GbE in a compact 1U form factor and together with the modular Aruba 8400 Switch, rounds out the Aruba Mobile First switching portfolio with an enterprise core and aggregation solution.
Aruba 8320 32 40G X472 5 2 Bdl
Specifications
JL579A
General Information
Specifications:
Switching capacity: 2.5Tbps
Forwarding performance: 1.905Mpps
Virtual interfaces (VLANs) per port for 802.1q: 4096
MAC Address Table Size: 14K entries
Jumbo Frame Support: 9KB
Memory
Flash Memory Installed Size: 8 MB
RAM (installed): 16 GB, 8 MB
RAM Technology: Flash, RAM
Memory Notes
2.0GHz processor
16GB RAM
8MB Flash memory
Ports/Connectors
I/O:
(32) 40GbE LAN QSFP+
(1) RJ-45 serial
(1) micro-USB console
(1) RJ-56
(2) Power in
Power
# Power Supplies Installed: 2
# Power Supplies Supported: 2
Power Provided: 800 watt(s)
Power Notes
(2) 400W internal hot-plug power supplies
1+1 power redundancy
Voltage required: 120 to 230V AC, 50 to 65Hz
Operational power consumption: 310W
Cooling:
(5) Redundant hot-swap fans
Processor
# Processors Installed: 1
Processor Speed: 2 GHz
Protocols
Networking Protocol: 40 Gigabit Ethernet, Gigabit Ethernet, IEEE 802.1S (MSTP), IEEE 802.1w (RSTP), IGMP, IGMP v2, IGMP v3, IPv4, IPv6, OSPF, QOS, RADIUS, SSH, TACACS+
Remote Management Protocol: CLI, RMON, SFTP, SNMP, SNMP 2c, SNMP 3, SSH, TFTP
Routing Protocol: ECMP, GRE, IGMP, IGMPv2, IGMPv3, OSPF, Static IPv6 routing, VRRP
